Maximum PV input voltage 100V ;
3-Stage charge to extend your battery life ;
Discharge mode: ON/OFF mode, PV voltage control mode.
Battery Range : 9V-60V;For AGM / Lithium / Gel / Flooded Batteries;
Intelligent LCD : System/PV/BAT Voltage;BAT Charging Current/watt/kwh/temp/Type;Load Mode.
2 years warranty, and 3~10 years extended warranty service also can be provided
1.If you want to connect PC/Laptop,you need to buy an communication cable,YS485.If there is no Communication cable,it`s only can be work for AGM,Flooded,Sealed Batteries.
2.Please be sure your solar panel input voltage is higher than 16V.
Charge Mode:MPPT(Maximum Power Point Tracking)
Max PV Input: 130V (Voc)
Rated charge current: 40A
Max Input Power:
520W (12v battery system)
1040W (24v battery system)
1560W (36v battery system)
2080W (48v battery system)
12V battery system:DC9V~DC15V
24V battery system:DC18V~DC30V
36V battery system:DC32V~DC40V
48V battery system:DC42V~DC60V
Constant Voltage:Please check the charge voltage according to the battery type form Contant Voltage(CV) Floating Voltage (CF):
Flooded: CV 14.6V CF 13.8V
Sealed: CV 14.4V CF 13.8V
Gel: CV 14.2V CF 13.8V
User(setting) : CV (9V~15V) CF (9V~15V)(You need to setup by PC,and you need to buy an YS485 Communication cable)
1.1PCS 40A MPPT solar charge controller
2.1PCS English User Manual
3.1PCS Temp. Sensor
4.2pcs Hang Bracket
Features & details
The 3rd generation of MPPT Solar Controller 40a, Advance MPPT efficiency ≥99.5%, with 2 years warranty.
Intelligent LCD display of 40a charge controller shows detail information of System/PV/BAT Voltage, BAT Charging Current/watt/kwh/temp/Type and Load Mode.
Fit for AGM / Lithium / Gel / Flooded Batteries; Charge Controller's Battery Range: 9V-60V; Three stages (fast charge, constant charge, floating charge) charging to prolong your battery's service life.
PV Max. voltage(VOC)130V, Max. Power of Solar panel: 2080W(48V),1560(36V);1040(24V);520W(12V)
Four Charage mode control of this charge controller: ON/OFF mode, PV voltage control mode, Dual Time control mode, PV&Time control mode.
Product information 40a solar controller
Parcel Dimensions 29.4 x 20.8 x 10.5 cm; 2.2 kg
Shipping Weight 2.2 kg
